ABS CCS BV LR Certified Shipbuilding Steel Plate Ah32 Ah36 Dh36 Eh36 Hot Rolled Marine Steel Sheet For Shipyard

ABS CCS BV LR Certified Shipbuilding Steel Plate Ah32 Ah36 Dh36 Eh36 Hot Rolled Marine Steel Sheet For Shipyard

To be considered a marine grade, the material must be able to resist corrosive effects that are common in a water environment. To achieve this, special alloying elements are added to these grades in order to defend against corrosion. While most carbon steel is not suited for marine environments, there are several marine grade carbon steels that have been approved by the American Bureau of Shipping for use in shipbuilding applications.

As a vital material for the ocean engineering sector, steel plays a crucial role in transportation, shipbuilding as well as marine engineering. However, marine environments can be very demanding on steel materials in these areas as all activities must be very safe and reliable under extremely severe climates and environments.

Quantity:
Material:	Ah32 Ah36 Dh36 Eh36
Classification Society Certificate:	ABS,BV, LR,CCS,DNV,GL Etc.
Thickness:	3-100MM
Width:	1250-1500mm, 1250-2500mm
Production Capacity:	50,000Ton/Month
Surface:	Clean, Finishing, Blasting and Painting
Delivery State:	Hot Rolled, Quenched, Tempered, Normalizing, etc.
Availability:





Inquire Add to Basket

Model:
ABS/CCS/BV/LR
Brand:
HONGKUN
Code:
72085190.00

Product Description

Shipbuilding Plate General Introduction:

Modern shipbuilding steel plate is well suited for the manufacturing of boats, ships, marine vessels, and other structures, as it is light in weight, high in tensile strength, and better in corrosion resistance than any other traditional shipbuilding steel plate, making it much better for more efficient construction. Most of the offshore and marine structures are created using carbon and alloy steel plates. Ship hulls, upper decks, bulkheads, anchor chains, bulk carriers, as well as container ships all rely on the material properties of these shipbuilding steels.

In addition to this, steels also play a decisive role in marine engineering projects, and they can be found everywhere as they involve offshore oil platforms, piers, and vessels. Steel with alloying elements enhanced its durability as well as anti-rust and anti-corrosion capability. Structures last longer when made from special steels grade, and they can resist the corrosion that is often found in other steel or alternative materials.

船板1

Shipbuilding Steel Plate Specification:

Shipbuilding Steel Plate/Marine Steel Plate/Vessel Steel Sheet
Standard	CCS,ABS,GL,BV,DNV,NK,LR,KR,RINA
Grade	A/B/D/E,A32/D32/E32/F32,A36/D36/E36/F36,A40/D40/E40/F40,A131A/B/D/E/AH32 /DH32/EH32/AH36/DH36/EH36/AH40/DH40/EH40,NVA420/D420/E420,NVA460 /D460/E460,NVA500/D500/E500,NVA550/D550/E550….
Thickness	3-100mm
Width	1000-3000mm (1000-2200mm usually used)
Length	1000-12000mm or as your request
Surface	Clean, finishing,blasting and painting according to customer requirement
Delivery States	Hot-rolled, Controlled rolling, Normalizing, Annealing, Tempering, Quenching, N+T, Q+T,and other delivery states are available as required
Certificate	API,ISO,SGS,BV,CE etc
Quality	MTC will be provided with goods, third part inspection is acceptable, for example BV,SGS.
Package	Standard export seaworthy package,suit for all kinds of transport, or as required.
Container Size	20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)
Container Size	40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)
Trade term	Ex-Work,FOB,CNF,CFR,CIF,etc
Application	Widely used in a variety of architectural and engineering structures,such as 1.) metal constructions such as buildings,bridges,ships; 2.) transmission tower, reaction tower; 3.) lifting transportation machinery;

Shipbuilding Steel Plate Chemical Composition and Mechanical Properties

Grade	C	Si	Mn	P	S	Als
A	≤0.21	≤0.50	≥2.5C	≤0.035	≤0.035
B	≤0.21	≤0.35	0.8~1.2	≤0.035	≤0.035
D	≤0.21	≤0.35	0.6~1.2	≤0.035	≤0.035	≥0.015
E	≤0.18	≤0.35	0.7~1.2	≤0.035	≤0.035	≥0.015
AH32	≤0.18	≤0.50	0.9~1.6	≤0.035	≤0.035	≥0.015
DH32	≤0.18	≤0.50	0.9~1.6	≤0.035	≤0.035	≥0.015
EH32	≤0.18	≤0.50	0.9~1.6	≤0.035	≤0.035	≥0.015
AH36	≤0.18	≤0.50	0.9~1.6	≤0.035	≤0.035	≥0.015
DH36	≤0.18	≤0.50	0.9~1.6	≤0.035	≤0.035	≥0.015
EH36	≤0.18	≤0.50	0.9~1.6	≤0.035	≤0.035	≥0.015
AH40	≤0.18	≤0.50	0.9~1.6	≤0.035	≤0.035	≥0.015
DH40	≤0.18	≤0.50	0.9~1.6	≤0.035	≤0.035	≥0.015
EH40	≤0.18	≤0.50	0.9~1.6	≤0.035	≤0.035	≥0.015

Grade	Yield Strength MPA	Tensile Strength MPA	Elongation %	Test Temperature °C	V Ballistic Work
					Thickness mm
					≤50		>50~70		>70~100
					L	T	L	T	L	T
A	≥235	400-520	≥22	20			34	24	41	27
B	≥235	400-520	≥22	0	27	20	34	24	41	27
D	≥235	400-520	≥22	-20	27	20	34	24	41	27
E	≥235	400-520	≥22	-40	27	20	34	24	41	27
AH32	≥315	440-570	≥22	0	31	22	38	26	46	31
DH32	≥315	440-570	≥22	-20	31	22	38	26	46	31
EH32	≥315	440-570	≥22	-40	31	22	38	26	46	31
AH36	≥355	490-630	≥21	0	34	24	41	27	50	34
DH36	≥355	490-630	≥21	-20	34	24	41	27	50	34
EH36	≥355	490-630	≥21	-40	34	24	41	27	50	34
AH40	≥390	510-660	≥20	0	41	27
DH40	≥390	510-660	≥20	-20	41	27
EH40	≥390	510-660	≥20	-40	41	27
